Composite Aircraft Technology Express instrument panel
The Express panel template at the panel's dimensions, 44 × 13.8 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
10 panels laid out on this template
What builders put in an Express panel
The equipment placed most often across the 10 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin International, Inc G5 | 4 | 40% |
| Garmin International, Inc G3X Touch | 3 | 30% |
| Garmin International, Inc GTN 750 | 2 | 20% |
| ISSPRO Fuel Pressure Gaiuge | 2 | 20% |
| Bendix King KT 76C | 2 | 20% |
| Garmin International, Inc GTR 200 | 2 | 20% |
| JPI Instruments EDM-350 | 2 | 20% |
| Garmin International, Inc GFC 500 | 2 | 20% |
From layout to fabricated panel
Lay out the Express panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
