Documentation
Expenses:  $14500.00
Hours:  2.00
Mar 11, 2023

Sat down with Panel Designer to document what I have.

Documented the grounding block on the rear of the panel.  Made some changes to the configuration of the FlightDek D180 so it can sit on the bench and not constantly alarm.  Items like current sensor where I am only using a battery for now.  The existing diffuse LEDs in the panel are a sloppy fit, the plastic fittings they sit in a not tight, will be replacing those.  Mostly working on minor things, getting ready for major changes.

Panel Layout wiring
