Cessna 170B instrument panel
The 170B panel template at the panel's dimensions, 31 × 8 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
96 panels laid out on these 2 templates
2 templates for the 170B
Recent 170B panel designs
Exported by builders from the Panel Designer, newest first.
170B for sale
Selling a 170B? List it on the Hangar Flying Marketplace, where builders and owners look.
What builders put in a 170B panel
The equipment placed most often across the 96 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Vertical Speed Indicator | 35 | 36% |
| Garmin International, Inc GI 275 ADI | 32 | 33% |
| Falcon Gauge Altimeter 3" | 32 | 33% |
| Falcon Gauge Airspeed Indicator 3" | 30 | 31% |
| Garmin International, Inc GI 275 EIS | 29 | 30% |
| Garmin International, Inc GI 275 HSI | 26 | 27% |
| uAvionix Corporation AV-30 PFD | 18 | 19% |
| Electronics International Inc CGR-30P Engine Analyzer | 18 | 19% |
Other Cessna panels
From layout to fabricated panel
Lay out the 170B panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
