Piper Aircraft PA-20/22 instrument panel
The PA-20/22 panel template at the panel's dimensions, 39.06 × 9.83 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
120 panels laid out on this template
Recent PA-20/22 panel designs
Exported by builders from the Panel Designer, newest first.
PA-20/22 for sale
Selling a PA-20/22? List it on the Hangar Flying Marketplace, where builders and owners look.
What builders put in a PA-20/22 panel
The equipment placed most often across the 120 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Altimeter 3" | 54 | 45% |
| Falcon Gauge Airspeed Indicator 3" | 50 | 42% |
| Falcon Gauge Vertical Speed Indicator | 49 | 41% |
| Sensa Technologies 7277 | 32 | 27% |
| uAvionix Corporation AV-30 PFD | 26 | 22% |
| Garmin International, Inc G5 | 22 | 18% |
| RC Allen Instruments / Kelly Manufacturing Company Turn & Slip Indicator 3" | 20 | 17% |
| Flightcom 403 | 18 | 15% |
