Piper Aircraft PA-28
PA-28 panel with Aspen Evolution
29 builders have laid out a PA-28 panel with the Aspen Evolution in the Panel Designer, 7% of the PA-28 builders here. Their newest designs, what they put beside it, and the PA-28 template to start your own, to scale.
49 PA-28 designs with the Aspen Evolution
PA-28 panels with the Aspen Evolution
Exported by builders from the Panel Designer, newest first.
What builders put beside the Aspen Evolution
The equipment placed most often in the 49 PA-28 designs with the Aspen Evolution. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Airspeed Indicator 3" | 28 | 57% |
| Falcon Gauge Altimeter 3" | 27 | 55% |
| Falcon Gauge Vertical Speed Indicator | 22 | 45% |
| Honeywell Sensing Rocker Switch | 19 | 39% |
| Aircraft Spruce & Specialty Keyed Ignition Switch | 18 | 37% |
| Mid Continent MD93 Digital Clock | 17 | 35% |
| Trig Avionics TI106 CDI | 14 | 29% |
| ACK Technologies ELT | 13 | 27% |
| Bendix King KX 155 | 12 | 24% |
| Sensa Technologies 7277 | 12 | 24% |
Other avionics in the PA-28
From layout to fabricated panel
Lay out the PA-28 panel with the Aspen Evolution in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
