Piper Aircraft PA22-108 instrument panel
The PA22-108 panel template at the panel's dimensions, 38.13 × 10.5 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
15 panels laid out on these 2 templates
2 templates for the PA22-108
Recent PA22-108 panel designs
Exported by builders from the Panel Designer, newest first.
PA22-108 for sale
Selling a PA22-108? List it on the Hangar Flying Marketplace, where builders and owners look.
What builders put in a PA22-108 panel
The equipment placed most often across the 15 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Vertical Speed Indicator | 8 | 53% |
| Falcon Gauge Airspeed Indicator 3" | 6 | 40% |
| uAvionix Corporation AV-30 PFD | 5 | 33% |
| Falcon Gauge Altimeter 3" | 4 | 27% |
| uAvionix Corporation AV-30 HSI | 4 | 27% |
| Garmin International, Inc GI 275 ADI | 3 | 20% |
| Falcon Gauge Altimeter 2" | 3 | 20% |
| Electronics International Inc CGR-30P Engine Analyzer | 3 | 20% |
