Van's Aircraft RV-6
RV-6 panel with Dynon D10
27 builders have laid out an RV-6 panel with the Dynon D10 in the Panel Designer, 9% of the RV-6 builders here. Their newest designs, what they put beside it, and the RV-6 template to start your own, to scale.
50 RV-6 designs with the Dynon D10
RV-6 panels with the Dynon D10
Exported by builders from the Panel Designer, newest first.
What builders put beside the Dynon D10
The equipment placed most often in the 50 RV-6 designs with the Dynon D10. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Dynon Avionics Autopilot Panel | 28 | 56% |
| Dynon Avionics Knob Control | 24 | 48% |
| Aircraft Spruce & Specialty Keyed Ignition Switch | 20 | 40% |
| Sensa Technologies 7277 | 20 | 40% |
| Dynon Avionics Dynon SkyView HDX 10" | 19 | 38% |
| Dynon Avionics VHF COM | 19 | 38% |
| SteinAir Air Vent | 19 | 38% |
| ACR Electronics ARTEX ELT-200 Remote Switch | 17 | 34% |
| Garmin GPS 175 | 15 | 30% |
| APPAREO Stratus Power USB Charger | 15 | 30% |
Other avionics in the RV-6
The Dynon D10 in other aircraft
From layout to fabricated panel
Lay out the RV-6 panel with the Dynon D10 in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
