Van's Aircraft RV-7/9
RV-7/9 panel with Dynon D10
42 builders have laid out an RV-7/9 panel with the Dynon D10 in the Panel Designer, 6% of the RV-7/9 builders here. Their newest designs, what they put beside it, and the RV-7/9 template to start your own, to scale.
60 RV-7/9 designs with the Dynon D10
RV-7/9 panels with the Dynon D10
Exported by builders from the Panel Designer, newest first.
What builders put beside the Dynon D10
The equipment placed most often in the 60 RV-7/9 designs with the Dynon D10. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Aircraft Spruce & Specialty Keyed Ignition Switch | 36 | 60% |
| ACK Technologies ELT | 30 | 50% |
| Dynon Avionics Autopilot Panel | 28 | 47% |
| Dynon Avionics Knob Control | 26 | 43% |
| Dynon Avionics VHF COM | 26 | 43% |
| Dynon Avionics Dynon SkyView HDX 10" | 21 | 35% |
| Sensa Technologies 7277 | 18 | 30% |
| Honeywell Sensing Rocker Switch | 18 | 30% |
| Falcon Gauge Altimeter 3" | 17 | 28% |
| Falcon Gauge Airspeed Indicator 3" | 16 | 27% |
Other avionics in the RV-7/9
The Dynon D10 in other aircraft
From layout to fabricated panel
Lay out the RV-7/9 panel with the Dynon D10 in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
