Van's Aircraft RV-8
RV-8 panel with Garmin G3X Touch
184 builders have laid out an RV-8 panel with the Garmin G3X Touch in the Panel Designer, 39% of the RV-8 builders here. Their newest designs, what they put beside it, and the RV-8 template to start your own, to scale.
436 RV-8 designs with the Garmin G3X Touch
RV-8 panels with the Garmin G3X Touch
Exported by builders from the Panel Designer, newest first.
What builders put beside the Garmin G3X Touch
The equipment placed most often in the 436 RV-8 designs with the Garmin G3X Touch. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin G5 | 307 | 70% |
| Garmin GMC 507 | 295 | 68% |
| SteinAir Air Vent | 193 | 44% |
| Aircraft Spruce & Specialty Keyed Ignition Switch | 150 | 34% |
| Garmin GMA 245 | 129 | 30% |
| ACK Technologies ELT | 104 | 24% |
| Garmin GNX 375 | 87 | 20% |
| Garmin GTR 200 | 74 | 17% |
| The Ray Allen Trim Indicator | 70 | 16% |
| Garmin GTN 650Xi | 70 | 16% |
Other avionics in the RV-8
The Garmin G3X Touch in other aircraft
From layout to fabricated panel
Lay out the RV-8 panel with the Garmin G3X Touch in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
