Garmin G5, GFC 500 and GMC
Garmin's G5 flight and HSI instruments with the GFC 500 autopilot and its mode controllers. Each piece is drawn to scale in the Panel Designer's library: place it on your aircraft's panel template, and the bill of materials lists it with its part number.
6,907 panel designs carry it
Garmin G5, GFC 500 and GMC in the library
The number on each is how many designs carry it.
G5
GMC 507
GFC 500
GMC 507
The configurator
Place one on your panel and the bill of materials works out the rest of the system from the manufacturer's installation manual, each line with its part number and the page it comes from.
Garmin G5
- Installation kit (one for each G5)
- Backup battery (up to 4 hours)
- Magnetic heading (GMU 11 magnetometer)
- Outside air temperature (GAD 13 with GTP 59 probe)
- External GPS antenna (the G5's own antenna does in many installations)
- Autopilot servos (GSA 28) driven by the G5
Garmin GFC 500 and GMC
- Optional
The aircraft it goes into most
Designs on each aircraft's panel templates that carry it.
What builders place with it
The equipment most often in the same 6,907 designs. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin G3X Touch | 3,529 | 51% |
| Sensa Technologies 7277 | 1,861 | 27% |
| Falcon Gauge Airspeed Indicator 3" | 1,463 | 21% |
| Falcon Gauge Altimeter 3" | 1,438 | 21% |
| ACK Technologies ELT | 1,423 | 21% |
| Falcon Gauge Vertical Speed Indicator | 1,317 | 19% |
| Garmin GMA 245 | 1,276 | 18% |
| Garmin GNX 375 | 1,147 | 17% |
